Scott
Voltage eRIDE 920 Bike

Rahmen
Carbon HMF
Integrated Suspension Technology
Virtual 4 Link kinematic / Adjustable head angle
Syncros Cable Integration System
TQ HPR50 / UDH Interface / 12x148mm with 55mm Chainline
Range Extender Ready
Federweg
Front: 150mm / Rear: 155mm
Gabel
Marzocchi Z2 Air Rail
3 modes / 15x110mm QR axle / tapered steerer
44mm offset / Reb. Adj. / Lockout / 150mm travel
Dämpfer
FOX Float Custom EVOL Performace Trunnion
3 modes / Lockout-Trail-Descend
DPS / Reb. Adj.
Travel 155mm / T185X55mm
Lenker-fernbedienung
SCOTT TwinLoc 2 Technology
Suspension & Dropper Remote
3 Suspension modes
Antriebseinheit
TQ HPR50 Mid Motor drive 50Nm max Torque / EU: 25kmh / US: 20mph
Batterie
TQ Internal 360Wh
Display
TQ HPR
Bluetooth / ANT+ / Dedicated Smartphone app
Ladegerät
TQ 100-240V-4A
Schaltwerk
Shimano XT RD-M8100 SGS
Shadow Plus / 12 Speed
Schalthebel
Shimano Deore SL-M6100-IR / Rapidfire Plus
I-spec EV clamp
Kurbelsatz
FSA Alloy crankset / 175mm / 34T
Kettenführung
e*thirteen / e*spec Slider
Kettenblatt
Scott custom spider / FSA 12Speed 34T chainring
Kette
Shimano CN-M6100
Kassette
Shimano CS-M6100 / 10-51 T
Bremsen
SRAM DB8 4 Piston Disc
Bremsscheibe
SRAM Centerline CL Rotors F&R 200mm
Lenker
Syncros Hixon 2.0 Alloy 6061 D.B.
12mm Rise / back sweep 8° / 780mm
Syncros Endurance lock-on grips
Vorbau
Syncros AM 2.0
Syncros Cable Integration System
4° rise / 6061 Alloy / 31.8mm / 1 1/8"
Sattelstütze
Syncros Duncan Dropper Post 1.5S / Travel Adjust / 31.6mm
S size 140mm / M size 180mm / L & XL size 210mm
Sattel
Syncros Tofino 2.0 Regular
Steuersatz
Syncros - Acros Angle adjust & Cable Routing HS System
Stainless / +-0.6° head angle adjustment
ZS56/28.6 – ZS56/40 MTB
Vorderradnabe
Formula CL-811 / 15x110mm
Hinterradnabe
Formula CL-148M / 12x148mm
Speichen
Stainless Black 15G / 1.8mm
Felgen
Syncros X-30S / 32H / 30mm / Sleeve Joint
Tubeless ready
Vorderreifen
Maxxis Dissector / 29x2.6" / 60TPI Wire Bead
EXO
Dual
Hinterreifen
Maxxis Dissector / 29x2.6" / 60TPI Wire Bead
EXO
Dual
Gewicht in Kg (ca.)
19.3 (with tubes)
Gewicht in Lbs (ca.)
42.55 (with tubes)
Max. Systemgewicht
128kg
Das Gesamtgewicht umfasst das Bike, den Fahrer, die Ausrüstung und eventuelles weiteres Gepäck.
